48 Square A-TYPE Ventilator

DRAWING

CHARACTERISTICS

TYPE	NO LOAD						DIMENSION		INS. CLASS	WATER PROOF
	V	Hz	W	RPM	TORQUE(kg·cm)		(A)	(B)
	V	Hz	W	RPM	MAXIMOM TORQUE	STARTING TORQUE	Φ	mm
4808-A	110 ~ 240	50	5~7	2700~2850	0.007~0.017	0.004~0.017	Φ4	8	E,B	X
4808-A		60	5~7	3250~3500	0.006~0.023	0.005~0.022	Φ5	8	E,B	X
4810-A		50	6~7	2700~2850	0.008~0.022	0.008~0.022		10	E,B	X
4810-A		60	6~7	3250~3500	0.007~0.026	0.006~0.014		10	E,B	X
4816-A		50	7~8	2700~2850	0.008~0.060	0.008~0.051		16	E,B	X
4816-A		60	7~8	3250~3500	0.008~0.063	0.008~0.054		16	E,B	X
4820-A		50	8~13	2700~2850	0.009~0.103	0.009~0.065		20	E,B	X
4820-A		60	8~13	3250~3500	0.010~0.068	0.010~0.057		20	E,B	X
4825-A		50	10~15	2700~2850	0.027~0.210	0.027~0.156		25	E,B	X
4825-A		60	10~15	3250~3500	0.065~0.135	0.041~0.019		25	E,B	X
4830-A		50	12~17	2700~2850	0.035~0.225	0.028~0.177		30	E,B	X
4830-A		60	12~17	3250~3500	0.052~0.192	0.043~0.139		30	E,B	X
